Commercial Dust Resistant Hvls Industrial Ceiling Fans Hvls Warehouse Fans

MOQ:	1Pcs
Price:	USD500-USD5000/SET
Standard Packaging:	With regular Film and Carton
Delivery Period:	3 DAYS After Deposit
Payment Method:	T/T,D/A,Western Union,MoneyGram
Supply Capacity:	1500SET/MONTH

Details Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Certification

CE,ISO,SGS

Hight:

7.3m

Type:

Permanent Magnet Brushless Internal Rotor

Name:

Industrial Industrial High-Volume Fan

Feature:

360 Degree Rotation Pole Pedestal

Usage:

Industrial

Power (W):

0.66KW

Voltage (V):

220v/50HZ

Diameter(meter):

12ft

Highlight:

Commercial Hvls Industrial Ceiling Fans

Dust Resistant Hvls Industrial Ceiling Fans

Dust Resistant Hvls Warehouse Fans

Product Description

7.3 meter Super Large Permanent Magnet Brushless Internal Rotor Industrial Fan

Product Description

Logistics and Warehousing: Logistics warehouses, e-commerce operation warehouses, express delivery sorting centers.

Leisure and Tourism: Large amusement parks, parks, tourist attractions, characteristic towns, catering.

Sports: Cultural centers, stadiums, gyms, indoor training grounds.

Commercial Public Places: Large shopping malls, supermarkets, professional wholesale markets, exhibition centers, showrooms, car 4S shops.

Manufacturing: Industrial plants, production workshops.

Parameters

Model	Diameter	Power Supply	Max. Current (Amps)	Power	Max Speed	Max Air Volume (m³/min)	Noise Level (dB)	Weight (KG)	Area Covered (m²)	Blades Qty	Remarks
RDF-S3600	3600mm (12ft)	Single 220V/50HZ	2.6A	0.66KW	90 RPM	4522	<38	72	20-24	5	Small Diameter
RDF-S4200	4200mm (14ft)	Single 220V/50HZ	2.6A	0.66KW	80 RPM	5306	<38	75	22-26	5	Small Diameter
RDF-S5200	5200mm (17ft)	Single 220V/50HZ	2.6A	0.66KW	70 RPM	7065	<39	78	25-30	5	Small Diameter
RDF-B6200	6200mm (20ft)	Single 220V/50HZ	4.5A	1.3KW	60 RPM	10747	<39	100	32-37	5	Large Diameter
RDF-B6200	6200mm (20ft)	Three 380V/50HZ	3.1A	1.3KW	60 RPM	10747	<39	100	32-37	5	Large Diameter
RDF-B6700	6700mm (22ft)	Single 220V/50HZ	4.5A	1.3KW	55 RPM	12560	<39	105	35-40	5	Large Diameter
RDF-B6700	6700mm (22ft)	Three 380V/50HZ	3.1A	1.3KW	55 RPM	12560	<39	105	35-40	5	Large Diameter
RDF-H7200	7200mm (24ft)	Single 220V/50HZ	4.5A	1.3KW	58 RPM	15197	<39	115	38-44	5	High Air Volume
RDF-H7200	7200mm (24ft)	Three 380V/50HZ	3.1A	1.3KW	58 RPM	15197	<39	115	38-44	5	High Air Volume

Feature

1. Help reduce temperature by 3 degrees to 5 degrees
2. Can cover an area up to 22, 000 square feet.
3. Costs just pennies to operate.
4. Lowers summer energy consumption by at least 20%
5. Reduces winter energy consumption by up to 30%
6. Can replace up to 20 floor fans or smaller ceiling fans
7. Keep fresh air circulating to reduce bacteria, smoke, and mildew. Prevent damage caused by excessive moisture by helping keep these areas dry.
8. A cool and comfortable work environment allows your employees to perform at their best and deliver more effectively on company goals.

Advantages

Exceptional Airflow: Provides high-volume airflow, effectively cooling large areas and improving ventilation in industrial and commercial settings.
360-Degree Rotation: Allows for complete directional airflow, ensuring even distribution of air throughout the space and enhancing comfort.
Durable and Sturdy: Constructed with high-quality materials designed to withstand harsh environments, ensuring long-term reliability and performance.
Adjustable Height: The pedestal design enables height adjustments, allowing for targeted airflow at various levels and adaptability to different spaces.
Energy Efficiency: Engineered to deliver powerful airflow while consuming less energy, reducing overall operational costs.
Portability: Lightweight and equipped with wheels, making it easy to move the fan to different locations as needed.
Low Maintenance: Designed for easy cleaning and maintenance, minimizing downtime and ensuring consistent performance.
Versatile Use: Suitable for a variety of applications, including warehouses, factories, workshops, and outdoor events.
