50Hz/380V Ventilation Exhaust Fan 250W 8000m³/H Corrosion Resistant
  • Name

50Hz/380V Ventilation Exhaust Fan 250W 8000m³/H Corrosion Resistant

MOQ: 1Pcs
Price: USD500-USD5000/SET
Standard Packaging: With regular Film and Carton
Delivery Period: 3 DAYS After Deposit
Payment Method: T/T,D/A,Western Union,MoneyGram
Supply Capacity: 1500SET/MONTH
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
KC
Certification
CE,ISO,SGS
Type:
Ventilation Fan
Frequency:
50Hz
Weight:
2.5kg
External Size:
40-60m²
Power Consumption:
250W
Power Supply:
50 Hz/380 V
Fan Blade Material:
Fiberglass
Air Flow:
8000 M³/h
Highlight:

250W Ventilation Exhaust Fan

,

250W industrial exhaust fan

,

8000m³/H Ventilation Exhaust Fan

Product Description

Blade Direct Drive Negative Pressure Fan System Longitudinal





Product Description



This document outlines the specifications for a series of negative pressure fans, categorized by model number and increasing size and performance. These fans are designed for industrial and commercial ventilation, providing effective air circulation and exhaust capabilities for various space sizes. The models range from the smaller 560 to the larger 1460, offering a range of options to suit different ventilation needs.

Size and Power: As the model number increases, so does the physical size of the fan and its power consumption.
Coverage Area: Larger models are designed to effectively ventilate larger areas.
Airflow: The airflow rate (air volume per hour) increases significantly with larger models, providing greater ventilation capacity.
Voltage: The voltage is approximately 380V across all models, suggesting they are designed for similar electrical systems (likely three-phase power).





Technical parameters



Model specification 560 660 850 1060 1260 1460
Body size/MM 560*560 660*660 850*850 1060*1060 1260*1260 1460*1460
Input power 250W 370W 370W 550W 750W 1100W
Applicable area 40-60m² 60-80m² 80-100m² 100-120m² 120-140m² 140-180m²
Voltage 380V 381V 382V 383V 384V 385V
Air volume/h 8000m3 1000m 3 13000m3 2800m3 4000m3 4400m3





Specifications



1. Material : Krupp 430 stainless steel, thickness 1.2mm
2. Diameter: 1270mm
3. Brand: Chinese  motor Certificate: CCC Protection class: IP55 grade
4. Insulation class: F grad
5. Volt and frequency:Customized Production:With phase failure protective device to ensure motor working well
6. Advantage:Pure copper wire,High-efficiency,Energy-saving.
7. Blade material also have galvanized sheet, aluminum alloy for option
8. Large air flow, no deformation, no fracture, no dust, attractive and durable.



Feature



1)  Reasonable cone designing with big air volume ,low noise.
2)  Imported bearing,high -strength ,low noise and long service life.
3)  Shutter are made of high strength fiber glass sheet,antioxidant, light weight and no distortions.
4)  High strength dabber aluminium-magnesium alloy wheel,high strength and long service life;
5)  Mirror designed and injection moulding stainless steel blade,with big air volume,never distortion and broken.





Tags:

negative pressure exhaust fan,

negative pressure ventilation fan,

negative air exhaust fan
