Multi Application High Performance Warehouse Swamp Cooler Eco Friendly Air Cooler
  • Name

Multi Application High Performance Warehouse Swamp Cooler Eco Friendly Air Cooler

MOQ: 1Pcs
Price: USD500-USD5000/SET
Standard Packaging: With regular Film and Carton
Delivery Period: 3 DAYS After Deposit
Payment Method: T/T,D/A,Western Union,MoneyGram
Supply Capacity: 1500SET/MONTH
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
KC
Certification
CE,ISO,SGS
Features:
High Performance Wet Curtain
Max Airflow Rate:
22000(m3/h)
Style:
Side Air Outlet
Evaporation Rate:
78L/h
Noise Level:
≤75Db(A)
Power Source:
Electric
Model:
KM22
Function:
Automatic Drainage Function
Highlight:

Multi Application Warehouse Swamp Cooler

,

Multi Application Eco Friendly Air Cooler

,

High Performance Warehouse Swamp Cooler

Product Description

Multi-Application High-Performance Air Coolera Eco-Friendly





Feature



Multi-Application High-Performance Air Coolera
High-Performance Wet Curtain: Utilizes advanced wet curtain technology to enhance cooling efficiency.
Automatic Cleaning Function: Prevents scaling on the wet curtain, extending its lifespan and ensuring optimal performance.
Automatic Drainage Function: Efficiently removes excess water, preventing stagnation and maintaining hygiene.
Office Spaces: Maintains optimal temperature for productivity.
Restaurants and Cafés: Creates a pleasant atmosphere for dining customers.
Warehouses: Regulates temperature for stored products and equipment.
High-Speed Train Maintenance Workshops: Supports a controlled environment for maintenance tasks.
Laundry and Dry Cleaning Services: Keeps workspaces cool and comfortable.
Public Facilities: Delivers efficient cooling in various communal spaces.


Technical Parameter



Feature KM22AA(3PH) KM22BA(3PH) KM22CA(3PH)
Model KM22AA(3PH) KM22BA(3PH) KM22CA(3PH)
Air Outlet Type Bottom Air Outlet Side Air Outlet Top Air Outlet
Max Air Volume 22000 m³/h 22000 m³/h 22000 m³/h
Standard Air Volume 15000 m³/h 14000 m³/h 15000 m³/h
Voltage/Frequency/Phase 380-415/50/3 V/Hz/Ph 380-415/50/3 V/Hz/Ph 380-415/50/3 V/Hz/Ph
Rated Input Power/Current 1.8 KW/A 1.8 KW/A 1.8 KW/A
Sensible Cooling Capacity 58 KW 51 KW 58 KW
Evaporation Efficiency 80% 76% 80%
Evaporation Rate 78 L/h 75 L/h 78 L/h
Noise (Sound Pressure Level) 70 dB(A) 70 dB(A) 70 dB(A)
Water Tank Capacity 40 L 40 L 40 L
Air Outlet Size 777×777 mm 777×777 mm 777×777 mm
Unit Size 1225×1225×1125 mm 1305×1225×1125 mm 1225×1225×1145 mm
Net Weight 87 Kg 86 Kg 88 Kg
Operating Weight 141 Kg 137 Kg 142 Kg





Installation technical requirements:


1. The roof stent must have sufficient strength to withstand the weight of environmentally friendly air conditioners and maintenance personnel;
2. The size of the roof opening should not be greater than the installation size of the air duct;
3. The installation host must be horizontally displaced within the allowable tolerance range;
4. All zinc-iron tile duct openings must be waterproofed.
Environmentally friendly air conditioner reinforced concrete roof air supply installation





Technical requirements:


1. Use 40*40*4 corner iron frame to connect and fix it with reinforced concrete bolts;
2. The roof truss must have sufficient strength to withstand the weight of environmentally friendly air conditioner maintenance personnel;
3. The size of the roof opening should not be greater than the installation size of the air duct;
4. The installation host must be horizontally displaced within the allowable tolerance range;
5. All roof air duct outlets must be waterproofed.
